Description
The SY8208BQNC integrates a high-efficiency buck regulator with internal switches and supports a wide input voltage range, making it suitable for applications such as notebooks, set-top boxes, and other electronics requiring stable lower voltages.
✅ Key Specifications & Features
-
Input voltage range: 4 V to 28 V
-
Delivers 8 A continuous current and 16 A peak (for transient loads)
-
Internal MOSFETs with low on-resistance: ~20 mΩ (high-side) / ~10 mΩ (low-side)
-
Instant-PWM architecture for fast transient response
-
Pseudo‑constant switching frequency: ~800 kHz in continuous conduction mode
-
Soft-start time: ~400 µs to limit inrush current at startup
-
Package: QFN, 3 × 3 mm, 10-pin (QFN3x3-10)
-
Protection and features:
-
Over-current protection (OCP)
-
Over-voltage protection (OVP)
-
Thermal shutdown
-
Output discharge at shutdown
-
Internal compensation (no external loop components needed)
-
⚙ Typical Use / Applications
-
Provides stable rails in notebooks, monitors, set-top boxes, and other embedded systems
-
Often used for generating 3.3 V or similar core voltages from higher bus voltages
-
In repair forums, people have identified this part (marking “MS3”) on laptop boards labeled “PU401,” supplying 3.3 V output
